Earth Station Antennas

1.2m Earth Station Antenna

Online consulting:

The Probecom 1.2M Ku-Band Tx/Rx is designed for environment,suitable for the most demanding application.The reflector is thermostet-molded for strength and surface accuracy,also it is made of glass fiber.The precision Az/El mount is constructed from heavy-gauge steel to provide a rigid support to the reflector. The Az/El mount secures the antenna to any 73-76 mm mast and prevents slippage in high winds.


- One-piece precision offset thermoset-molded reflector

- Polarization: Linear Cross Pol
- Tx Operating Frequency: 13.75 - 14.5 GHz
- Rx Operating Frequency: 10.7 - 12.75 GHz
- Az/El mount includes both elevation and azimuth fine adjustments.
- Plated hardware for maximum corrosion resistance
